| Brand Name : | OUCO |
| Model Number : | OUCO-0.35T3.5M-TB |
| Certification : | ABS/BV/CCS |
| Price : | Negotiation |
| Payment Terms : | T/T, Western Union |
| Supply Ability : | 300 units per year |
| Delivery Time : | 20 days |
3.5m Ship Yacht Electric 0.35T Hydraulic Telescopic Crane
Capable of being loaded to its full safe working load capacity in any position without restriction.
The intelligent engineering inherent in this design allows distributed load-deflection across the boom during moments of dynamic loading, reducing the amount of shock-loading transmitted to the deck.
Virtually silent-operating Hydraulic Linear Winch system, a totally non-fouling winch design reflects the innovative and dependably safe operating characteristics built into this crane.
Features 359° hydraulic power rotation providing the ultimate handling convenience.
Remotely operated with a proportional joy-stick control on a removable pendant.
Optional wireless proportional control available.
A pedestal base is the typical mounting structure. A floating-flange standpipe mount may also be used in some applications.
| SWL | 0.35T@3.5M |
| MAX WORKING RADIUS | 3.5m |
| MIN WORKING RADIUS | 1m |
| HOISTING SPEED | 0~15m/min |
| HOISTING HEIGHT | 10m |
| SLEWING SPEED | ~0.5r/min |
| SLEWING ANGLE | 360° |
| LUFFING TIME | ~ 45s |
| EXTENSION TIME | ~45s |
| WORKING CONDITION | TRIM ≤2° HEEL ≤5° |
| ELEC-MOTOR POWER | Y160K-4-H |
| POWER | 4.5kw |
| Speed | 1475r/min |
| POWER RESOURCE | AC415V/50HZ |
| PROTECT CLASS | IP56 |
| INSUKATE CLASS | F |
| WORKING TYPE | S1 |
General Arrangement Drawing:
|
|
